SpringBoot启动源码分析

作者：松哥哥

源码环境

操作系统：Windows 11

JDK 版本：JDK 11

SpringBoot 版本：2.7.5

源码分析

启动开始

// 启动开始
SpringApplication.run();

实例化 SpringApplication

// 实例化Spring应用配置
public SpringApplication(ResourceLoader resourceLoader, Class<?>... primarySources) {
    this.sources = new LinkedHashSet();
    this.bannerMode = Mode.CONSOLE;
    this.logStartupInfo = true;
    this.addCommandLineProperties = true;
    this.addConversionService = true;
    this.headless = true;
    this.registerShutdownHook = true;
    this.additionalProfiles = Collections.emptySet();
    this.isCustomEnvironment = false;
    this.lazyInitialization = false;
    this.applicationContextFactory = ApplicationContextFactory.DEFAULT;
    this.applicationStartup = ApplicationStartup.DEFAULT;
    this.resourceLoader = resourceLoader;
    Assert.notNull(primarySources, "PrimarySources must not be null");
    this.primarySources = new LinkedHashSet(Arrays.asList(primarySources));
    // 根据Classpath推断WEB应用类型
    this.webApplicationType = WebApplicationType.deduceFromClasspath();
    // 根据启动注册初始化器获取Spring工厂实例
    this.bootstrapRegistryInitializers = new ArrayList(this.getSpringFactoriesInstances(BootstrapRegistryInitializer.class));
    // 根据应用上下文初始化器获取Spring工厂实例设置初始化器
    this.setInitializers(this.getSpringFactoriesInstances(ApplicationContextInitializer.class));
    // 根据应用监听器获取Spring工厂实例设置监听器
    this.setListeners(this.getSpringFactoriesInstances(ApplicationListener.class));
    // 推断主应用类
    this.mainApplicationClass = this.deduceMainApplicationClass();
}

根据 Classpath 推断 WEB 应用类型

static WebApplicationType deduceFromClasspath() {
    if (ClassUtils.isPresent("org.springframework.web.reactive.DispatcherHandler", (ClassLoader)null) && !ClassUtils.isPresent("org.springframework.web.servlet.DispatcherServlet", (ClassLoader)null) && !ClassUtils.isPresent("org.glassfish.jersey.servlet.ServletContainer", (ClassLoader)null)) {
        return REACTIVE;
    } else {
        String[] var0 = SERVLET_INDICATOR_CLASSES;
        int var1 = var0.length;
         for(int var2 = 0; var2 < var1; ++var2) {
            String className = var0[var2];
            if (!ClassUtils.isPresent(className, (ClassLoader)null)) {
                return NONE;
            }
        }
         return SERVLET;
    }
}

可以看到 SpringBoot 在推断 WEB 应用类型时会去 Classpath 下用 ClassUtils 工具持久化一些类，然后判断出是 REACTIVE、NONE、SERVLET 三种类型中的某一种，通常情况下都是 SERVLET 类型。

根据 Class 获取 Spring 工厂实例

// 获取Spring工厂实例集
private <T> Collection<T> getSpringFactoriesInstances(Class<T> type, Class<?>[] parameterTypes, Object... args) {
    // 获取类加载器
    ClassLoader classLoader = this.getClassLoader();
    // 根据类加载器加载工厂名字
    Set<String> names = new LinkedHashSet(SpringFactoriesLoader.loadFactoryNames(type, classLoader));
    List<T> instances = this.createSpringFactoriesInstances(type, parameterTypes, classLoader, args, names);
    AnnotationAwareOrderComparator.sort(instances);
    return instances;
}
// 加载工厂名单
public static List<String> loadFactoryNames(Class<?> factoryType, @Nullable ClassLoader classLoader) {
    ClassLoader classLoaderToUse = classLoader;
    if (classLoader == null) {
        classLoaderToUse = SpringFactoriesLoader.class.getClassLoader();
    }
     String factoryTypeName = factoryType.getName();
    return (List)loadSpringFactories(classLoaderToUse).getOrDefault(factoryTypeName, Collections.emptyList());
}
// 加载Spring工厂
private static Map<String, List<String>> loadSpringFactories(ClassLoader classLoader) {
    Map<String, List<String>> result = (Map)cache.get(classLoader);
    if (result != null) {
        return result;
    } else {
        Map<String, List<String>> result = new HashMap();
         try {
            Enumeration<URL> urls = classLoader.getResources("META-INF/spring.factories");
             while(urls.hasMoreElements()) {
                URL url = (URL)urls.nextElement();
                UrlResource resource = new UrlResource(url);
                Properties properties = PropertiesLoaderUtils.loadProperties(resource);
                Iterator var6 = properties.entrySet().iterator();
                 while(var6.hasNext()) {
                    Map.Entry<?, ?> entry = (Map.Entry)var6.next();
                    String factoryTypeName = ((String)entry.getKey()).trim();
                    String[] factoryImplementationNames = StringUtils.commaDelimitedListToStringArray((String)entry.getValue());
                    String[] var10 = factoryImplementationNames;
                    int var11 = factoryImplementationNames.length;
                     for(int var12 = 0; var12 < var11; ++var12) {
                        String factoryImplementationName = var10[var12];
                        ((List)result.computeIfAbsent(factoryTypeName, (key) -> {
                            return new ArrayList();
                        })).add(factoryImplementationName.trim());
                    }
                }
            }
             result.replaceAll((factoryType, implementations) -> {
                return (List)implementations.stream().distinct().collect(Collectors.collectingAndThen(Collectors.toList(), Collections::unmodifiableList));
            });
            cache.put(classLoader, result);
            return result;
        } catch (IOException var14) {
            throw new IllegalArgumentException("Unable to load factories from location [META-INF/spring.factories]", var14);
        }
    }
}

三个方法实现了从当前所有依赖包里扫描“META-INF/spring.factories”文件内容，加载文件里配置内容存放到内存缓存 Map 里。扫描到的顺序如下：

jar:file:/C:/Users/Administrator/.m2/repository/org/springframework/spring-beans/5.3.23/spring-beans-5.3.23.jar!/META-INF/spring.factories

org.springframework.beans.BeanInfoFactory=org.springframework.beans.ExtendedBeanInfoFactory

jar:file:/C:/Users/Administrator/.m2/repository/org/springframework/boot/spring-boot-autoconfigure/2.7.5/spring-boot-autoconfigure-2.7.5.jar!/META-INF/spring.factories

# Initializers
org.springframework.context.ApplicationContextInitializer=\
org.springframework.boot.autoconfigure.SharedMetadataReaderFactoryContextInitializer,\
org.springframework.boot.autoconfigure.logging.ConditionEvaluationReportLoggingListener

# Application Listeners
org.springframework.context.ApplicationListener=\
org.springframework.boot.autoconfigure.BackgroundPreinitializer

# Environment Post Processors
org.springframework.boot.env.EnvironmentPostProcessor=\
org.springframework.boot.autoconfigure.integration.IntegrationPropertiesEnvironmentPostProcessor

# Auto Configuration Import Listeners
org.springframework.boot.autoconfigure.AutoConfigurationImportListener=\
org.springframework.boot.autoconfigure.condition.ConditionEvaluationReportAutoConfigurationImportListener

# Auto Configuration Import Filters
org.springframework.boot.autoconfigure.AutoConfigurationImportFilter=\
org.springframework.boot.autoconfigure.condition.OnBeanCondition,\
org.springframework.boot.autoconfigure.condition.OnClassCondition,\
org.springframework.boot.autoconfigure.condition.OnWebApplicationCondition

# Failure analyzers
org.springframework.boot.diagnostics.FailureAnalyzer=\
org.springframework.boot.autoconfigure.data.redis.RedisUrlSyntaxFailureAnalyzer,\
org.springframework.boot.autoconfigure.diagnostics.analyzer.NoSuchBeanDefinitionFailureAnalyzer,\
org.springframework.boot.autoconfigure.flyway.FlywayMigrationScriptMissingFailureAnalyzer,\
org.springframework.boot.autoconfigure.jdbc.DataSourceBeanCreationFailureAnalyzer,\
org.springframework.boot.autoconfigure.jdbc.HikariDriverConfigurationFailureAnalyzer,\
org.springframework.boot.autoconfigure.jooq.NoDslContextBeanFailureAnalyzer,\
org.springframework.boot.autoconfigure.r2dbc.ConnectionFactoryBeanCreationFailureAnalyzer,\
org.springframework.boot.autoconfigure.r2dbc.MissingR2dbcPoolDependencyFailureAnalyzer,\
org.springframework.boot.autoconfigure.r2dbc.MultipleConnectionPoolConfigurationsFailureAnalzyer,\
org.springframework.boot.autoconfigure.r2dbc.NoConnectionFactoryBeanFailureAnalyzer,\
org.springframework.boot.autoconfigure.session.NonUniqueSessionRepositoryFailureAnalyzer

# Template availability providers
org.springframework.boot.autoconfigure.template.TemplateAvailabilityProvider=\
org.springframework.boot.autoconfigure.freemarker.FreeMarkerTemplateAvailabilityProvider,\
org.springframework.boot.autoconfigure.mustache.MustacheTemplateAvailabilityProvider,\
org.springframework.boot.autoconfigure.groovy.template.GroovyTemplateAvailabilityProvider,\
org.springframework.boot.autoconfigure.thymeleaf.ThymeleafTemplateAvailabilityProvider,\
org.springframework.boot.autoconfigure.web.servlet.JspTemplateAvailabilityProvider

# DataSource initializer detectors
org.springframework.boot.sql.init.dependency.DatabaseInitializerDetector=\
org.springframework.boot.autoconfigure.flyway.FlywayMigrationInitializerDatabaseInitializerDetector

# Depends on database initialization detectors
org.springframework.boot.sql.init.dependency.DependsOnDatabaseInitializationDetector=\
org.springframework.boot.autoconfigure.batch.JobRepositoryDependsOnDatabaseInitializationDetector,\
org.springframework.boot.autoconfigure.quartz.SchedulerDependsOnDatabaseInitializationDetector,\
org.springframework.boot.autoconfigure.session.JdbcIndexedSessionRepositoryDependsOnDatabaseInitializationDetector

设置初始化器

this.setInitializers(this.getSpringFactoriesInstances(ApplicationContextInitializer.class));

从当前所有依赖包里扫描“META-INF/spring.factories”文件内容，获取 ApplicationContextInitializer 实现类排序后返回设置，如下：

0 = {DelegatingApplicationContextInitializer@2388}
1 = {SharedMetadataReaderFactoryContextInitializer@2389}
2 = {ContextIdApplicationContextInitializer@2390}
3 = {ConfigurationWarningsApplicationContextInitializer@2391}
4 = {RSocketPortInfoApplicationContextInitializer@2392}
5 = {ServerPortInfoApplicationContextInitializer@2393}
6 = {ConditionEvaluationReportLoggingListener@2394}

设置监听器

this.setListeners(this.getSpringFactoriesInstances(ApplicationListener.class));

从当前所有依赖包里扫描“META-INF/spring.factories”文件内容，获取 ApplicationListener 实现类排序后返回设置，如下：

0 = {EnvironmentPostProcessorApplicationListener@2473}
1 = {AnsiOutputApplicationListener@2474}
2 = {LoggingApplicationListener@2475}
3 = {BackgroundPreinitializer@2476}
4 = {DelegatingApplicationListener@2477}
5 = {ParentContextCloserApplicationListener@2478}
6 = {ClearCachesApplicationListener@2479}
7 = {FileEncodingApplicationListener@2480}

推断主应用类

private Class<?> deduceMainApplicationClass() {
    try {
        StackTraceElement[] stackTrace = (new RuntimeException()).getStackTrace();
        StackTraceElement[] var2 = stackTrace;
        int var3 = stackTrace.length;
        for(int var4 = 0; var4 < var3; ++var4) {
            StackTraceElement stackTraceElement = var2[var4];
            if ("main".equals(stackTraceElement.getMethodName())) {
                return Class.forName(stackTraceElement.getClassName());
            }
        }
    } catch (ClassNotFoundException var6) {
    }
    return null;
}
